The AeroCatch Extreme is the latest edition to the hugely popular range and is designed for heavy duty applications such as rally raid / off road vehicles. Designed with all the benefits of the original AeroCatch but with the addition of higher tensile strength zinc plated steel strike pins.
The aerodynamically efficient and aesthetically styled AeroCatch is setting new standards in panel fixing, providing a wide variety of fixing solutions for bodywork on Motorsport vehicles. The PTFE coated strike pins virtually eliminate the need for regular lubrication and can be used through the base or side, making them suitable for bonnets or boots.
There are two types of AeroCatch available; 'Above Panel' (was called Plus Flush) and 'Below Panel' (was called Flush). Both types available in a choice of locking or non-locking.
Above Panel kit (120 Series) is designed to be fixed through the top surface of a panel with six M4 countersunk screws. The fitting flange will be 2.5mm above the panel surface. Ideal for thin metallic or composite panels.
Below Panel kit (125 Series) is designed to be fixed from underneath the panel thereby creating a flush surface and can be bonded into position so that there are no fasteners visible from the top of the panel. Ideally suited for composite panels.
- 2 x AeroCatch Bodies
- 2 x Nut Fixing Plates
- 2 x Zinc Plated Steel Strike Pins
- 2 x Bump Stops
- 1 x Fastener Kit
- 1 x Arrow Sticker Kit
- 1 x Aerocatch Cardboard Template
